4. Web Management in SNMP-FSH2602MG v2
31
AirLive SNMP-FSH2602MG v2 User’s Manual
4.4.5.3 State Activity
When setup the LACP aggregator, you can configure port state activity. You can mark or
un-mark the port. When you mark the port and click “Apply” button, the port state activity
will change to Active. Opposite is Passive.
1. Active: The port automatically sends LACP protocol packets.
2. Passive: The port does not automatically send LACP protocol packets, and responds
only if it receives LACP protocol packets from the opposite device.
Note:
„ A link having either two active LACP ports or one active port can perform dynamic
LACP trunking.
„ A link having two passive LACP ports will not perform dynamic LACP trunking
because both ports are waiting for LACP protocol packet from the opposite device.
„ If you are active LACP’s actor, when you are selecting trunking port, the active
status will be created automatically.
