AirLive IP-2000VPN User’s Manual 35
Data – Virtual Servers Screen
Servers
Servers This lists a number of pre-defined Servers, plus any Servers you have defined.
Details of the selected Server are shown in the "Properties" area.
Properties
Enable Use this to Enable or Disable support for this Server, as required.
• If Enabled, any incoming connections will be forwarded to the selected PC.
• If Disabled, any incoming connection attempts will be blocked.
PC (Server)
Select the PC for this Server. The PC must be running the appropriate Server
software.
Defining your own Virtual Servers
If the type of Server you wish to use is not listed on the Virtual Servers screen, you can use the Firewall
Rules to allow particular incoming traffic and forward it to a specified PC (Server).
Connecting to the Virtual Servers
Once configured, anyone on the Internet can connect to your Virtual Servers. They must use the Internet IP
Address (the IP Address allocated to you by your ISP).
e.g.
http://203.70.212.52
ftp://203.70.212.52
It is more convenient if you are using a Fixed IP Address from your ISP, rather than Dynamic. However, you
can use the Dynamic DNS feature, described in the following section, to allow users to connect to your Virtual
Servers using a URL, rather than an IP Address.
