Setting Type Value Notes
Name To_RS12 Name does not affect operation. Select
a meaningful name.
Enable Policy
Enable
Allow NetBIOS
traffic
Enable Enable to allow NetBIOS passing
through VPN tunnel
Remote Endpoint Domain Name airlive98.dyndns
.org
The domain name resolved the other
endpoint's WAN (Internet) IP address.
Local IP addresses Subnet Address 192.168.1.0 /
255.255.255.0
Allows access to entire LAN. Use a
more restrictive definition if possible.
Remote IP
addresses
Subnet Address 192.168.100.0 /
255.255.255.0
Address range on other endpoint.
Use a more restrictive definition if
possible.
Step 2: IP-2000VPN –Authentication and Encryption
