AirLive IP-2000VPN - Manual (Page 138)

AirLive IP-2000VPN User’s Manual 135
update the messages shown on screen.
Buttons
Connect
If not connected, establish a connection to your ISP.
Disconnect If connected to your ISP, hang up the connection.
Clear Log Delete all data currently in the Log. This will make it easier to read new
messages.
Refresh
Update the data on screen.
Connection Log Messages
Message Description
Connect on Demand Connection attempt has been triggered by the "Connect automatically, as
required" setting.
Manual connection
Connection attempt started by the "Connect" button.
Reset physical
connection
Preparing line for connection attempt.
Connecting to remote
server
Attempting to connect to the ISP's server.
Remote Server located ISP's Server has responded to connection attempt.
Start PPP Attempting to login to ISP's Server and establish a PPP connection.
PPP up successfully Able to login to ISP's Server and establish a PPP connection.
Idle time-out reached The connection has been idle for the time period specified in the "Idle
Time-out" field. The connection will now be terminated.
Disconnecting The current connection is being terminated, due to either the "Idle Time-out"
above, or "Disconnect" button being clicked.
Error: Remote Server
not found
ISP's Server did not respond. This could be a Server problem, or a problem
with the link to the Server.
Error: PPP Connection
failed
Unable to establish a PPP connection with the ISP's Server. This could be a
login problem (name or password) or a Server problem.
Error: Connection to
Server lost
The existing connection has been lost. This could be caused by a power
failure, a link failure, or Server failure.
Error: Invalid or
unknown packet type
The data received from the ISP's Server could not be processed. This could
be caused by data corruption (from a bad link), or the Server using a protocol
which is not supported by this device.
