SECTION 2 - GROUND COMPONENTS
3121640
3369LE/4069LE/M3369/M4069
93
FIGURE 2-3. HYDRAULIC COMPARTMENT INSTALLATION
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
0270518
Ref
HYDRAULIC COMPARTMENT INSTALLATION
H
1
0182014
1
Angle
2
0641507
1
Bolt 5/16-18 X 7/8
4
0641618
2
Bolt 3/8-16 X 2-1/4
5
0700812
2
Bolt M8 X 25
6
1120534
1
Cap/Breather
7
3160252
1
Motor Assembly (See MOTOR ASSEMBLY for Breakdown)
8
3311505
9
Nut 5/16-18
10
3600367
1
Pump Assembly
10
7024960
1
Seal Kit (Note: If repairs beyond seal kit are required, replace
complete pump)
11
4400433
1
Tank, Hydraulic
13
4740076
2
Washer
14
4751500
10
Washer 5/16
16
4891500
2
Washer 5/16
18
0100011
AR
Compound, Locking
19
1060900
1
Cable, Contactor (B+ to Pump)
20
1060901
1
Cable, Contactor (Pump to Ground)
21
3020037
AR
Lubricant, Pump Coupling
22
0902701
1
Bracket, Pump/Motor
23
3311401
1
Nut 1/4-20
24
0641404
1
Bolt 1/4-20 X 1/2
25
0641506
8
Bolt 5/16-18 X 3/4
26
2220377
1
Fitting, Straight JIC/ORB
27
4568203
1
Tube
28
1320033
1
Clamp
29
3311605
2
Nut 3/8-16
30
4711600
2
Washer 3/8
