SECTION 4 - SCISSORS ARMS
3121640
3369LE/4069LE/M3369/M4069
161
FIGURE 4-5. SCISSORS ARMS INSTALLATION WITHOUT LSS - 4069LE/M4069
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
0272933
Ref
SCISSORS ARMS INSTALLATION WITHOUT LSS -
4069LE/M4069
J
17
0440234
4
Bushing
19
0641408
2
Bolt 1/4-20 x 1
21
0641610
2
Bolt 3/8-16 x 1-1/4
22
0681520
2
Bolt 5/16-18 x 2-1/2 Grade 8
25
3900325
2
Screw #10-24
26
0721014
2
Screw #10-24
27
0902713
1
Bracket, Limit Switch
29
1670965
1
Cover, Limit Switch
33
3020022
AR
Lubricant
36
3311405
4
Nut 1/4-20
37
3311505
2
Nut 5/16-18
38
3311605
2
Nut 3/8-16
39
3311001
2
Nut #10-32
40
3340856
2
Pad, Slide
43
3422822
2
Pin, Pivot
46
3422905
1
Pin, Pivot
47
3422907
1
Pin, Pivot
49
3760387
4
Ring, Retaining
51
3841143
2
Keeper, Pin
52
4360500
1
Switch, Rotary Angle Sensor
52
77363243
1
Receptacle, Female - 3 Position
52
4460464
3
Pin, Male
53
4360502
1
Switch, Proximity Sensor
53
4460897
1
Receptacle, Female - 2 Position
53
4460464
2
Pin, Male
56
4711400
8
Washer 1/4
60
4751000
8
Washer #10
63
1001099550
2
Slider
63A
0440234
4
Bushing
77
3200453
1
Block
77
0903273
1
Bracket
78
0100035
AR
Compound, Locking
79
4922543
1
Harness, Lift Down (Lower) (Not Shown - See ELECTRICAL
SECTION for Breakdown)
80
3300455
2
Nut #10-24
82
0791406
3
Screw 1/4-20 x 3/4
83
4740438
2
Washer
84
3422927
1
Rollpin
86
0641410
2
Bolt 1/4-20 x 1-1/4
87
4740506
2
Washer #10
88
0275482
1
Scissors Arms Assembly ISee SCISSORS ARMS ASSEMBLY
WITHOUT LSS - 4069LE/M4069 for Breakdown)
89
1001125244
1
Decal Kit - Calibration (Includes 2 Decals)
