Page 13
SECTION 1 - FRAME
3121640
3369LE/4069LE/M3369/M4069
13
FIGURE 1-1. REAR AXLE INSTALLATION - FIXED
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001165760
Ref
REAR AXLE INSTALLATION - FIXED
B
1
0100011
AR
Compound, Locking
2
0641408
6
Bolt 1/4-20 x 1
3
0641606
4
Bolt 3/8-16 x 3/4
4
0641610
4
Bolt 3/8-16 x 1-1/4
5
0641820
8
Bolt 1/2-13 x 2-1/2
6
0642012
1
Bolt 5/8-11 x 1-1/2
7
0961950
2
Bearing
8
2080061
6
Fastener
9
2540038
1
Grommet
10
2540039
1
Grommet
11
3311605
4
Nut 3/8-16
13
3422900
1
Pin
14
3572554
2
Plate, Cover
15
3841258
1
Keeper, Pin
16
4070932
4
Shim 16Ga
17
4071008
2
Shim
18
4711400
6
Washer 1/4
19
4711600
12
Washer 3/8
20
4740158
1
Washer
21
4891800
16
Washer 1/2
22
1001164150
1
Axle
23
1001165629
2
Support
25
3311805
8
Nut 1/2-13
26
1001165821
NLA
Plate, Cover (LH) (Use p/n 1001180299) (SN 0200230092
through 0200235754)
26
1001180299
1
Plate, Cover (LH) (SN 0200235755 to Present)
27
1001165821
NLA
Plate, Cover (RH) (Use p/n 1001180300) (SN 0200230092
through 0200235754)
27
1001180300
1
Plate, Cover (RH) (SN 0200235755 to Present)
