SECTION 2 - GROUND COMPONENTS
3121640
3369LE/4069LE/M3369/M4069
105
FIGURE 2-9. GROUND CONTROL BOX AND HORN INSTALLATIONS - M3369/M4069 (2WD - ALL
SPECS EXCEPT CE SPEC)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001171072
Ref
GROUND CONTROL BOX AND HORN INSTALLATIONS -
M3369/M4069 (2WD - ALL SPECS EXCEPT CE SPEC)
A
1
0140028
1
Alarm
2
0271442
1
Ground Control Box Assembly (See GROUND CONTROL BOX
ASSEMBLY - M3369 & M4069 ALL SPECS EXCEPT CE SPEC
for Breakdown)
3
0641406
9
Bolt 1/4-20 X 3/4
4
0902696
2
Bracket
5
3311405
5
Nut 1/4-20
6
4751400
6
Washer 1/4
7
4761400
4
Washer 1/4
8
4922602
1
Generator Harness (Not Shown - See ELECTRICAL SECTION for
Breakdown)
9
1001171103
1
Valve Harness (Not Shown - See ELECTRICAL SECTION for
Breakdown)
