Page 331
SECTION 9 - DECALS
3121640
3369LE/4069LE/M3369/M4069
331
FIGURE 9-1. DECAL INSTALLATION - ANSI SPEC (ENGLISH)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1283217
Ref
DECAL INSTALLATION - REFERENCE CHART
K
0270591
Ref
DECAL INSTALLATION - ANSI SPEC (ENGLISH)
7
1
0641405
4
Bolt 1/4-20 x 5/8
2
0860520
1
Box, Manual Storage
3
1060279
1
Cable, Lanyard
4
1001131270
1
Decal - Patent
5
1701644
1
Decal - Battery Charger
7
1702153
1
Decal - Inspection
8
1702155
2
Decal - Battery Disconnect
9
See Note
NSS
Decal - Barcode (Note: Not Available for Purchase)
10
1703816
1
Decal - Danger/Warning
11
1704211
1
Decal - Safety Prop
12
1704412
1
Decal - Hydraulic Oil
13
2080057
4
Fastener
14
3251813
1
Decal - USA
15
See Note
NSS
Nameplate - Serial Number (Note: Not Available for Purchase)
16
3311405
4
Nut 1/4-20
17
4711400
8
Washer 1/4
19
1701509
1
Decal - Manual
20
1703811
4
Decal - Lifting Lugs
21
1703812
1
Decal - Hydraulic Oil
22
1703814
4
Decal - Tie Down
23
1704277
8
Decal - Attach Lanyard Here
24
1703819
2
Decal - Directional Arrow
25
1703822
1
Decal - Manual Descent
34
1703687
2
Decal - Directional Arrow
36
1704911
1
Decal - Legend
37
1703818
4
Decal - Warning Crushing Hazard/Danger Electrocution
38
1703821
1
Decal - Control Box Location
39
1704903
1
Decal - Gradeability
40
1703813
2
Decal - Battery Warning
41
1704248
1
Decal - Battery Charger Instructions
50
2901912
1
Master Decal Kit (Not Shown) (Includes Items 19-25)
5
51
2902040
1
English Language Decal Kit (Not Shown) (Includes Items 36-41)
4
