SECTION 1 - FRAME
3121640
3369LE/4069LE/M3369/M4069
21
FIGURE 1-5. STEERING INSTALLATION - 4WD
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001165839
Ref
STEERING INSTALLATION - 4WD
B
1
0100011
1
Compound, Locking
3
0440162
4
Bearing, Thrust
4
0440247
1
Bearing
7
0641418
4
Bolt 1/4-20 x 2-1/4
9
0641607
2
Bolt 3/8-16 X 7/8
12
0902704
2
Bracket
13
0961951
4
Bushing
14
0962140
3
Bearing
16
1320292
1
Clamp
17
1683994
1
Steer Cylinder Assembly (See CYLINDER SECTION for
Breakdown)
21
3300240
4
Nut 5/8-11
22
3311405
8
Nut 1/4-20
24
3313003
2
Nut 1-1/4-7
25
3450812
2
Pin, Cotter
27
3841143
2
Keeper, Pin
28
3900266
4
Capscrew 5/8-11 x 2-1/4
29
4711400
12
Washer 1/4
30
4712200
16
Washer 3/4
31
4713000
2
Washer 1-1/4
32
4751600
10
Washer 3/8
33
4846301
1
Tie-Rod
34
1001097815
2
Spindle
37
1001165819
2
Pin
38
0641606
4
Bolt 3/8-16 x 3/4
