JLG M4069 Parts Manual User Manual
Page 91
SECTION 2 - GROUND COMPONENTS
3121640
3369LE/4069LE/M3369/M4069
91
FIGURE 2-2. MAIN CONTROL VALVE ASSEMBLY
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
4641178
Ref
MAIN CONTROL VALVE ASSEMBLY
E
1
7022391
1
Cartridge, Check (Brake)
1
7012967
1
Seal Kit - 7022391 Cartridge
2
7023904
1
Cartridge, Solenoid (Flow Control) (Cartridge Only)
2
7012518
1
Seal Kit - 7023904 Cartridge
2
7017451
1
Coil
3
7022392
1
Cartridge, Relief (Main)
3
7017496
1
Seal Kit - 7022392 Cartridge
4
7023931
1
Cartridge, Relief (Lift)
4
7017496
1
Seal Kit - 7023931 Cartridge
5
7023932
1
Cartridge, Relief (Steer)
5
7012998
1
Seal Kit - 7023932 Cartridge
6
7010542
1
Cartridge, Shuttle (Steer)
6
7010543
1
Seal Kit - 7010542 Cartridge
7
7012941
1
Cartridge, Solenoid (Brake) (Cartridge Only)
7
7010543
1
Seal Kit - 7022391 Cartridge
7
7012944
1
Coil
8
7022394
1
Cartridge, Solenoid (Lift) (Cartridge Only)
8
7012518
1
Seal Kit - 7022394 Cartridge
8
7012943
1
Coil
9
7017433
1
Cartridge, Check (Steer) (Cartridge Only)
9
7017402
1
Seal Kit - 7017433 Cartridge
9
7012944
2
Coil
10
7021616
1
Cartridge, Filter
11
7021619
1
Cartridge, Pressure Switch
12
7024832
1
Plug
13
70004264
1
Plug
