SECTION 3 - ENGINE
3121640
3369LE/4069LE/M3369/M4069
141
FIGURE 3-1. KUBOTA ENGINE/GENERATOR INSTALLATION - M3369/M4069
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001165843
Ref
KUBOTA ENGINE/GENERATOR INSTALLATION - M3369/M4069
B
1
0100011
AR
Compound, Locking
2
0100020
AR
Sealant, Pipe
4
0400201
1
Battery
6
0641418
4
Bolt 1/4-20 X 2-1/4
10
0641632
2
Bolt 3/8-16 X 4
11
0641660
2
Bolt 3/8-16 X 7-1/2
12
0902659
1
Bracket, Hold-Down
13
1060820
1
Cable, Battery (Battery + to Starter)
14
1060916
1
Cable, Battery (Generator
– to Controller –)
15
1060917
1
Cable, Battery (Lower Generator + to Contactor+)
16
1060950
1
Cable, Battery (Battery
– to Ground)
17
1320022
5
Clamp
19
1671010
1
Cover, Engine
21
1001159358
1
Kubota Motor/Generator Assembly (See KUBOTA
MOTOR/GENERATOR ASSEMBLY for Breakdown)
22
2220805
1
Fitting, 90 NPT/Barbed
27
2720271
10 ft /3m
Hose
28
2820135
1
Insulation
29
2820136
1
Insulation
30
2820137
1
Insulation
31
2820138
1
Insulation
32
2820228
1
Insulation
33
1001166302
1
Cover, Front (Includes PC Board)
33
1001165794
1
Cover, Front (Less PC Board)
33A
0610131
1
PC Board, LED Light
34
2940137
1
Latch
35
3300374
1
Nut
36
3311405
4
Nut 1/4-20
38
3311605
4
Nut 3/8-16
39
3322202
5
Nut
40
3760348
4
Ring, Retaining
41
3841233
4
Rod, Roller
42
3860059
4
Roller, Extension
43
3900184
1
Screw #10-24 X 5/8
44
3960389
2 ft /60cm
Seal
45
3960418
2 ft /60cm
Seal
46
4160189
1
Spring
48
4711400
8
Washer 1/4
51
4751600
6
Washer 3/8
52
4752200
4
Washer 3/4
