Page 239
SECTION 7 - HYDRAULIC
3121640
3369LE/4069LE/M3369/M4069
239
FIGURE 7-10. HYDRAULIC DIAGRAM - STANDARD - 4069LE/M4069 WITH OSCILLATING AXLE
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001167498
Ref
HYDRAULIC DIAGRAM - STANDARD - 4069LE/M4069 WITH
OSCILLATING AXLE
D
1
2220415
3
Fitting, Straight
2
2220371
1
Fitting, Straight
3
2220373
1
Fitting, Straight
4
2220504
2
Fitting, Tee
5
2230024
2
Fitting, Bulkhead
6
2221041
1
Fitting, Tee
7
2220466
5
Fitting, 90
8
2752958
1
Hose
9
1001170684
1
Hose
10
2752593
1
Hose
11
2752444
1
Hose
12
2753462
1
Hose
13
2752983
2
Hose
14
1001177692
1
Hose
15
2753528
1
Hose
16
1001170682
2
Hose
17
1001170683
1
Hose
18
1001170685
1
Hose
19
1001170686
1
Hose
20
1001170687
1
Hose
21
2220923
2
Fitting, Straight JIC/ORB
22
2220998
1
Fitting, Straight JIC/ORB
23
2220603
1
Fitting, Straight JIC/ORB
24
2220579
1
Fitting, Tee JIC/JIC/JIC
25
2220502
1
Fitting, 45 JIC/ORB
26
2220605
1
Fitting, Tee JIC/JIC/JIC
27
2220635
1
Fitting, Tee JIC/JIC/JIC
28
2220810
1
Fitting, Straight ORB/ORB
29
4640744
1
Valve, Inline Check
30
2221086
1
Fitting, Test Port
31
2220600
1
Fitting, Straight ORB
32
2220651
1
Fitting, Straight
33
2221044
1
Fitting, 45
34
4640757
1
Valve, Color Flow
35
2220775
1
Fitting, 90 JIC/ORB
37
2753187
1
Hose
