SECTION 7 - HYDRAULIC
3121640
3369LE/4069LE/M3369/M4069
223
FIGURE 7-2. HYDRAULIC DIAGRAM - LEVELING JACKS (OPTIONAL)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
2792494
Ref
HYDRAULIC DIAGRAM - LEVELING JACKS (OPTIONAL)
E
1
2753532
4
Hose
2
2753529
2
Hose
3
2753397
2
Hose
4
2753059
1
Hose
5
2750908
1
Hose
6
2750915
1
Hose
7
2220371
12
Fitting, Straight JIC/ORB
8
2220473
7
Fitting, 90 JIC/ORB
9
2220490
2
Fitting, Tee JIC/JIC/JIC
10
2220385
1
Fitting, Tee JIC/JIC/JIC
11
2220819
2
Fitting, 90 JIC/ORB
12
2753120
1
Hose
13
2753524
2
Hose
14
2220619
1
Fitting, Reducer JIC/JIC
15
2221089
4
Orifice (.0625)
