SECTION 5 - PLATFORM
3121640
3369LE/4069LE/M3369/M4069
185
FIGURE 5-5. HANDRAILS INSTALLATION WITH SELF-CLOSING GATE
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
0259566
Ref
HANDRAILS INSTALLATION WITH CHAIN GATE
G
1
4846123
2
Rail, Side
2
4846125
1
Rail, Rear (Right Side)
3
4846124
1
Rail, Rear (Left Side)
4
4845829
2
Retainer, Rail
9
3571829
1
Plate, Latch
11
0901870
2
Bracket
12
3421565
AR
Pin, Snap
13
3760170
AR
Ring, Split
15
0641516
3
Bolt 5/16-18 x 2
16
2080064
10
Nut 5/16-18
18
3311505
3
Nut 5/16-18
21
3900323
9
Screw 5/16-18 x 2
23
4751500
6
Washer 5/16
24
1260136
2 ft /61cm
Chain
26
2540020
1
Grommet
27
2820097
2 ft /.6m
Tubing, Mesh
28
2940064
1
Latch, Snap
29
3010088
2
Link
30
2080063
8
Nut 1/4-20
32
3340612
18 in
/46cm
Pad
33
3422369
2
Pin, Plunger
34
3641310
1
Rail, Entry
35
3911424
2
Screw 1/4-20 x 1-1/2
36
3900318
6
Screw 1/4-20 x 2
37
4711400
14
Washer 1/4
38
0100011
AR
Compound, Locking (Not Shown)
39
3422219
2
Pin, Snap
40
1060808
6
Lanyard
41
3911536
1
Screw 5/16-18 x 2-1/4
42
1320061
1
Clamp
