SECTION 6 - CYLINDER
3121640 3369LE/4069LE/M3369/M4069 211
FIGURE 6-3. LIFT CYLINDER ASSEMBLY - 3369LE/M3369
ITEM PART NUMBER QTY DESCRIPTION REV
1684119 Ref LIFT CYLINDER ASSEMBLY - 3369LE/M3369 D
1 See Note 1 Seal (Note: Use Item 50)
2 See Note 1 O-Ring (Note: Use Item 50)
3 See Note 1 Ring, Back-up (Note: Use Item 50)
4 See Note 1 O-Ring (Note: Use Item 50)
5 See Note 1 O-Ring (Note: Use Item 50)
6 See Note 1 Seal (Note: Use Item 50)
7 See Note 1 Wiper (Note: Use Item 50)
8 See Note 1 Ring, Wear (Note: Use Item 50)
9 See Note 1 Ring, Wear (Note: Use Item 50)
11 7003226 1 Locknut
15 0962012 4 Bushing
16 7019898 1 Barrel
17 70001358 1 Rod
18 7019886 1 Head
19 7024101 1 Piston
20 70001357 1 Spacer
50 7024103 1 Seal Kit (Includes Items 1-9)
