SECTION 7 - HYDRAULIC
3121640
3369LE/4069LE/M3369/M4069
233
FIGURE 7-7. HYDRAULIC DIAGRAM - STANDARD - 3369LE/M3369 WITH FIXED AXLE
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
2792443
Ref
HYDRAULIC DIAGRAM - STANDARD - 3369LE/M3369 WITH
FIXED AXLE
E
1
2220415
3
Fitting, Straight JIC/ORB
2
2220371
2
Fitting, Straight JIC/ORB
3
2220373
1
Fitting, Straight JIC/ORB
5
2220504
1
Fitting, Tee JIC/JIC/JIC
8
2230024
2
Fitting, Bulkhead JIC/JIC
9
2221041
1
Fitting, Tee
13
2220466
4
Fitting, 90 JIC/ORB
18
2752958
1
Hose
20
2752593
1
Hose
21
2752444
1
Hose
22
2750905
1
Hose
24
2752983
2
Hose
28
2753527
1
Hose
29
2753528
1
Hose
32
2753187
1
Hose
34
2220810
1
Fitting, Straight ORB/ORB
35
4640744
1
Valve, Inline Check
36
2221086
1
Fitting, Test Port
