SECTION 8 - ELECTRICAL
3121640 3369LE/4069LE/M3369/M4069 251
FIGURE 8-5. AC TO PLATFORM INSTALLATION - 220V IEC BLUE (CE SPEC ONLY)
ITEM PART NUMBER QTY DESCRIPTION REV
1001094912 Ref AC TO PLATFORM INSTALLATION - 220V IEC BLUE (CE SPEC
ONLY) B
1 0275217 1 Receptacle Box Kit - 220V IEC Blue (See RECEPTACLE BOX KIT
- 220V IEC BLUE for Breakdown)
2 0641407 2 Bolt 1/4-20 X 7/8
3 2902549 1 Breaker Box Kit (See BREAKER BOX KIT WITH TWO
BREAKERS - CE SPEC for Breakdown)
4 3252507 1 Decal - 220V - 50/60Hz
5 3290405 4 Nut M4
6 3290605 4 Nut M6
7 3300048 1 Nut 3/4NPT
8 3311405 2 Nut 1/4-20
9 4010408 4 Screw M4 X 16
10 4010608 4 Screw M6 X 16
11 4460071 1 Connector, Strain Relief
12 4460968 1 Connector, Strain Relief
13 4751400 2 Washer 1/4
15 4811400 8 Washer M4
16 4811700 4 Washer M6
17 1001151377 1 Bracket
18 1001094915 1 Bracket
