SECTION 1 - FRAME
3121640
3369LE/4069LE/M3369/M4069
15
FIGURE 1-2. REAR AXLE INSTALLATION - OSCILLATING
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001165761
Ref
REAR AXLE INSTALLATION - OSCILLATING
D
1
0100011
AR
Compound, Locking
2
0100038
AR
Primer, Locking
3
0641408
6
Bolt 1/4-20 x 1
4
0641610
4
Bolt 3/8-16 x 1-1/4
5
0701217
8
Bolt M12 x 45
6
0642012
1
Bolt 5/8-11 x 1-1/2
7
0961950
2
Bearing
8
1001163580
2
Axle Lockout Cylinder Assembly (See CYLINDER SECTION for
Breakdown)
9
2080061
6
Fastener
10
2540038
1
Grommet
11
2540039
1
Grommet
12
3311605
4
Nut 3/8-16
13
3422900
1
Pin
14
3572554
2
Plate, Cover
15
3841258
1
Keeper, Pin
16
4071008
2
Shim
17
4711400
6
Washer 1/4
18
4711600
8
Washer 3/8
19
4740158
1
Washer 1/4
20
5241200
8
Washer M12
21
1001164150
1
Axle
23
0641530
2
Bolt 5/16-18 x 3-3/4
24
3311505
2
Nut 5/16-18
25
4711500
4
Washer 5/16
26
1001166487
1
Oscillating Axle Valve Assembly (See OSCILLATING AXLE
VALVE ASSEMBLY for Breakdown)
27
1001165821
NLA
Plate, Cover (LH) (Use p/n 1001180299) (SN 0200230092
through 0200235754)
27
1001180299
1
Plate, Cover (LH) (SN 0200235755 to Present)
28
1001165821
NLA
Plate, Cover (RH) (Use p/n 1001180300) (SN 0200230092
through 0200235754)
28
1001180300
1
Plate, Cover (RH) (SN 0200235755 to Present)
