SECTION 1 - FRAME
3121640 3369LE/4069LE/M3369/M4069 25
FIGURE 1-7. WHEEL DRIVE AND CONTROLLER INSTALLATION - 2WD/4WD REAR
ITEM PART NUMBER QTY DESCRIPTION REV
1001099375 Ref WHEEL DRIVE AND CONTROLLER INSTALLATION - 2WD/4WD
REAR B
1 0100019 AR Compound, Locking
2 0100083 AR Grease, Heat Transfer
4 0641406 2 Bolt 1/4-20 X 3/4
5 0641412 4 Bolt 1/4-20 X 1-1/2
7 0641609 8 Bolt 3/8-16 X 1-1/8
8 0641826 4 Bolt 1/2-13 X 3-1/4
9 0682012 12 Bolt 5/8-11 X 1-1/2 Grade 8
11 0920118 1 Drive Brake Assembly (See DRIVE BRAKE ASSEMBLY for
Breakdown)
12 1060888 1 Cable, Electrical (Controller F2 to Right Motor F1)
13 1060889 1 Cable, Electrical (RH Motor F2 to LH Motor F2)
14 1060890 1 Cable, Electrical (Controller F1 to LH Motor F1)
15 1060891 1 Cable, Electrical (Controller S to LH Motor A2)
16 1060892 1 Cable, Electrical (RH Motor A1 to LH Motor A1)
17 1060893 1 Cable, Electrical (Controller A to RH Motor A1)
18 1060894 1 Cable, Electrical (LH Motor A2 to RH Motor A2)
19 1060895 1 Cable, Electrical (Controller B+ to Contactor ++)
20 1600421 1 Controller
21 2780282 2 Drive Hub Assembly (See DRIVE HUB ASSEMBLY - REAR for
Breakdown)
22 3020008 1.6
qt/1.5L
Lubricant 80W-90
23 3160256 2 Drive Motor Assembly - Rear (See DRIVE HUB ASSEMBLY -
REAR for Breakdown)
24 3311405 6 Nut 1/4-20
26 3740135 1 Contactor
27 4240084 1 Strap, Anti-Static
28 4711400 4 Washer 1/4
30 4711600 8 Washer 3/8
31 4751400 8 Washer 1/4
32 4892000 1 Washer 5/8
33 3020037 AR Lubricant
34 3941606 1 Screw 3/8-16 x 3/4
35 4751600 1 Washer 3/8
36 0903273 1 Bracket
