SECTION 1 - FRAME
3121640 3369LE/4069LE/M3369/M4069 33
FIGURE 1-10. DRIVE BRAKE ASSEMBLY - 2WD/4WD REAR
ITEM PART NUMBER QTY DESCRIPTION REV
0920118 Ref DRIVE BRAKE ASSEMBLY - 2WD/4WD REAR B
1 7007913 4 Bolt
2 See Note 4 Washer (Note: Not Available at Time of Printing)
3 See Note 1 Plate, Pressure (Note: Not Available - Use p/n 0920118)
4 See Note 1 Seal, Case (Note: Use p/n 7011757)
5 See Note 1 O-Ring (Note: Use p/n 7011757)
6 See Note 1 Ring, Back-up (Note: Use p/n 7011757)
7 See Note 1 Piston (Note: Not Available - Use p/n 0920118)
8 See Note 1 O-Ring (Note: Use p/n 7011757)
9 See Note 1 Ring, Back-up (Note: Use p/n 7011757)
10 See Note 1 Shaft (Note: Not Available - Use p/n 0920118)
11 See Note 1 Stator (Note: Use p/n 7011757)
12 See Note 1 Ring, Sensor (Note: Not Available - Use p/n 0920118)
13 See Note 1 Rotor (Note: Use p/n 7011757)
14 See Note 1 Plate, Return (Note: Use p/n 7011757)
15 See Note AR Spring (Note: Use p/n 7011757)
16 See Note 1 Guide, Spring (Note: Use p/n 7011757)
17 7007977 1 Ring, Retaining
18 2900768 1 Bearing Kit (Part of Repair Kit)
19 7011716 1 Ring, Retaining
20 See Note 2 Pin, Dowel (Note: Not Available - Use p/n 0920118)
21 See Note 1 Cover (Note: Not Available - Use p/n 0920118)
22 7007900 1 Seal, Oil - Front (Part of Repair Kit)
23 7007933 1 Gasket, Brake to Hub (Part of Repair Kit)
24 70002408 1 Gasket, Brake to Motor (Note: Not part of Repair Kit - Must be
Purchased Separately)
100 7011757 1 Repair Kit (Includes Items 4,5,6,8,9,11,13,14,15,18,22 & 23)
