SECTION 1 - FRAME
3121640 3369LE/4069LE/M3369/M4069 45
FIGURE 1-16. TIRE AND WHEEL INSTALLATION - IN240/55 X 17.5 FOAM-FILLED
ITEM PART NUMBER QTY DESCRIPTION REV
0270570 Ref TIRE AND WHEEL INSTALLATION - IN240/55 x 17.5 FOAM-
FILLED B
1 3300426 36 Lugnut
2 0258997 4 Tire and Wheel Assembly - IN240/55 x17.5 Foam-Filled C
101 4520209 1 Tire IN240/55 x 17.5
102 4860191 1 Rim, Wheel
103 4641122 1 Valve
Ref Note: Assemblies require ballast/foam filling to manufacturer’s
specification prior to installing on a machine. Refer to Operation
& Safety or Service & Maintenance Manuals. Purchase individual
tire and/or rim only if able to foam fill tire & wheel assembly,
otherwise, purchase complete assembly.
