Page 63
SECTION 1 - FRAME
3121640
3369LE/4069LE/M3369/M4069
63
FIGURE 1-25. BATTERY CHARGER INSTALLATION - 250V/50HZ (3369LE AND 4069LE ANSI EXPORT
AND AUSTRALIAN SPECS)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
NOTE: AVAILABLE ON 3369LE AND 4069LE ANSI EXPORT &
AUSTRALIAN SPEC.
1001166241
Ref
BATTERY CHARGER INSTALLATION - 250V/50HZ
B
1
0100011
AR
Compound, Locking
3
0641405
4
Bolt 1/4-20 x 5/8
5
0641509
4
Bolt 5/16-18 X 1-1/8
7
0642016
4
Bolt 5/8-11 x 2
9
0721008
4
Bolt #10-24 x 1
10
1060689
1
Cord, Electrical
14
3311001
4
Nut #10-24
15
3311405
4
Nut 1/4-20
16
3311505
4
Nut 5/16-18
18
3312005
4
Nut 5/8-11
19
3571584
1
Plate, Plug Inlet
20
4460428
1
Connector, Strain Relief
21
4460802
1
Cover, Weatherproof
22
4460805
1
Plug
24
4712000
8
Washer 5/8
25
4751000
4
Washer #10
26
4751500
8
Washer 5/16
27
1001103105
1
Battery Charger Assembly (See BATTERY CHARGER
ASSEMBLY for Breakdown)
28
1001165370
1
Plate, Support
30
1001166234
1
Battery Charger Door Assembly (See BATTERY CHARGER
DOOR ASSEMBLY for Breakdown)
