SECTION 6 - CYLINDER
3121640 3369LE/4069LE/M3369/M4069 207
FIGURE 6-1. AXLE LOCKOUT CYLINDER ASSEMBLY
ITEM PART NUMBER QTY DESCRIPTION REV
1001163580 Ref AXLE LOCKOUT CYLINDER ASSEMBLY D
1 1684290 1 Rod
2 2220890 2 Plug
3 4640858 1 Bleeder
4 1001117372 1 Cartridge, Counterbalance Valve
4 70002842 1 Seal Kit - 1001117372 Valve
5 1001164817 1 Barrel
100 2902266 1 Seal Kit, Cylinder (Includes Items 101-103)
101 See Note 2 Ring, Wear (Note: Use Item 100)
102 See Note 1 Seal, Wiper (Note: Use Item 100)
103 See Note 1 Seal, Rod (Note: Use Item 100)
