SECTION 8 - ELECTRICAL
3121640
3369LE/4069LE/M3369/M4069
255
FIGURE 8-7. AC TO PLATFORM INSTALLATION - 220V CEE7 SIDE GROUND (CE SPEC ONLY)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001162452
Ref
AC TO PLATFORM INSTALLATION - 220V CEE7 SIDE GROUND
(CE SPEC ONLY)
A
1
0275453
1
Receptacle Box Kit - 220V CEE7 Side Ground (See
RECEPTACLE BOX KIT - 220V CEE7 SIDE GROUND for
Breakdown)
2
0641407
2
Bolt 1/4-20 X 7/8
3
1001152485
1
Breaker Box Kit (See BREAKER BOX KIT WITH THREE
BREAKERS - CE SPEC for Breakdown)
4
3252507
1
Decal - 220V - 50/60Hz
5
3290405
6
Nut M4
6
3300048
1
Nut 3/4NPT
7
3311405
2
Nut 1/4-20
8
4010408
6
Screw M4 X 16
9
4460071
1
Connector, Strain Relief
10
4460662
1
Connector, Strain Relief
11
4751400
2
Washer 1/4
12
4811400
8
Washer M4
13
1001162456
1
Bracket
