SECTION 1 - FRAME
3121640
3369LE/4069LE/M3369/M4069
17
FIGURE 1-3. OSCILLATING AXLE VALVE ASSEMBLY
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001166487
Ref
OSCILLATING AXLE VALVE ASSEMBLY
B
1
70004387
1
Cartridge Less Coil
1
7010543
1
Seal Kit - 70004387 Valve
2
7017410
1
Cartridge Less Coil
2
7012967
1
Seal Kit - 7017410 Valve
2
70003978
1
Nut, Coil
3
70004388
1
Cartridge, Valve
3
7021653
1
Seal Kit - 70004388 Valve
4
70002963
2
Coil
5
7023976
1
Cartridge, Valve
5
7012967
1
Seal Kit - 7023976 Valve
6
7012955
1
Cartridge, Valve
6
7012967
1
Seal Kit - 7012955 Cartridge
7
70004389
1
Orifice
8
7017406
1
Plug
