Page 189
SECTION 5 - PLATFORM
3121640
3369LE/4069LE/M3369/M4069
189
FIGURE 5-7. PLATFORM EXTENSION INSTALLATION
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
0259565
Ref
PLATFORM EXTENSION INSTALLATION
L
1
4846117
1
Extension, Platform
2
3537619
4
Mount, Roller
3
3841233
4
Rod, Roller
4
3760348
4
Ring, Retaining
5
3860059
4
Roller, Extension
6
3322202
4
Nut 3/4
7
4846121
1
Rail, Side (Left Side)
8
4846120
1
Rail, Front
9
3537609
2
Plate, Pivot
10
4846191
1
Handle (Right Side)
11
4846181
1
Handle (Left Side)
13
2560088
2
Grip, Handle
15
0901870
2
Bracket
16
0182035
2
Angle, Stop
17
3020022
AR
Grease, Lithium (Not Shown)
18
3520072
4
Cap-Plug
20
3571862
1
Plate, Placard
21
3820020
7
Rivet
22
0681508
4
Bolt 5/16-18 x 1
23
0641516
4
Bolt 5/16-18 x 2
24
0641510
16
Bolt 5/16-18 x 1-1/4
25
0641676
2
Bolt 3/8-16 x 9-1/2
26
2080064
6
Nut 5/16-18
27
3311405
2
Nut 1/4-20
28
3311505
20
Nut 5/16-18
30
3900318
2
Screw 1/4-20 x 2
31
3900323
6
Screw 5/16-18 x 2
33
4711600
4
Washer 3/8
35
4711500
26
Washer 5/16
36
4752200
4
Washer 3/4
37
3422219
2
Pin, Snap
38
2080063
2
Nut 1/4-20
39
0100011
AR
Compound, Locking
40
3421565
2
Pin, Snap
41
1060808
4
Lanyard
42
3760170
4
Ring, Split
43
0641406
2
Bolt 1/4-20 x 3/4
44
0700619
2
Screw M6 x 55
45
2940127
2
Latch, Rubber
46
3290601
2
Nut M6
49
4751400
2
Washer 1/4
50
4846256
1
Rail, Side (Right Side)
52
0940090
2
Bumper
53
3311401
2
Nut 1/4-20
55
3300467
2
Nut, 3/8-16
56
3271505
1
Nut 5/16-18
57
4751600
2
Washer 3/8
58
4711400
2
Washer 1/4
