SECTION 5 - PLATFORM
3121640 3369LE/4069LE/M3369/M4069 197
FIGURE 5-11. CONSOLE BOX ASSEMBLY - M3369/M4069 2WD WITH LEVELING JACKS
ITEM PART NUMBER QTY DESCRIPTION REV
0270996 Ref CONSOLE BOX ASSEMBLY - M3369/M4069 2WD WITH
LEVELING JACKS G
1 0140011 1 Alarm
2 0181847 1 Angle, Latch
3 0610169 1 PC Board
4 0641404 4 Bolt 1/4-20 x 1/2
5 0861357 1 Box
6 0902499 1 Bracket, "D" Slot
7 1600403 1 Drive/Steer Controller Assembly (See DRIVE/STEER
CONTROLLER ASSEMBLY for Breakdown)
8 1704574 1 Decal - Outrigger
9 1705911 1 Decal - Platform Box (Upper)
10 1704921 1 Decal - Generator Enable M3369 & M4069
11 2560141 1 Thumbscrew
12 1705912 1 Decal - Platform Box (Lower)
13 3310601 4 Nut #6-32
15 3520080 1 Plug
16 3900178 4 Screw #10-32 x 1/2
17 3900265 10 Screw #8-18 x 3/4
18 4060802 2 Guard, Switch
19 4360387 7 Switch, Push Button
20 4360475 1 Switch, Emergency Stop
20 7020175 1 Ring, Sealing
20 7020176 1 Block, Contact
21 4360482 1 Switch, Toggle
23 4420008 38 in
/96cm
Tape, Insulation
24 4460470 1 Nut, Terminal
25 4460471 1 Lockwasher, Terminal
26 4460480 1 Connector, Terminal
27 4740120 12 Washer
28 4760600 4 Washer #6
29 4791400 4 Washer 1/4
30 4845938 1 Bracket, Box Hanger
31 4846249 1 Lid
32 4922527 1 Platform Console Box Harness (Not Shown - See ELECTRICAL
SECTION for Breakdown)
33 3520193 1 Plug
33 Ref Note: Components common with standard machines are called-out
in this figure. For LSS specific components, see JLG Load
Sensing System Supplement Manual p/n 3124288.
