Page 149
SECTION 4 - SCISSORS ARMS
3121640
3369LE/4069LE/M3369/M4069
149
FIGURE 4-1. SCISSORS ARMS INSTALLATION WITHOUT LSS - 3369LE/M3369
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
0272932
Ref
SCISSORS ARMS INSTALLATION WITHOUT LSS -
3369LE/M3369
J
15
0440234
4
Bushing
17
0641408
2
Bolt 1/4-20 x 1
20
0641610
2
Bolt 3/8-16 x 1-1/4
21
0681520
2
Bolt 5/16-18 x 2-1/2 Grade 8
24
3900325
2
Screw #10-24 x 1/2
25
0721014
2
Screw #10-24
26
0902713
1
Bracket, Limit Switch
27
1670965
1
Cover, Limit Switch
30
3020022
AR
Lubricant
32
3311405
4
Nut 1/4-20
33
3311505
2
Nut 5/16-18
34
3311605
2
Nut 3/8-16
35
3311001
2
Nut #10-32
36
3340856
2
Pad, Slide
40
3422822
2
Pin
43
3422905
1
Pin
44
3422907
1
Pin
46
3760387
4
Ring, Retaining
48
3841143
2
Keeper, Pin
49
4360500
1
Switch, Rotary Angle Sensor
49
77363243
1
Receptacle, Female - 3 Position
49
4460464
3
Pin, Male
50
4360502
1
Switch, Proximity Sensor
50
4460897
1
Connector, Female - 2 Position
50
4460464
2
Pin, Male
53
4711400
8
Washer 1/4
57
4751000
4
Washer #10
60
1271441
1
Channel, Arm Retainer (Not Shown)
66
3200453
1
Block, Mounting
66
0903273
1
Bracket, Switch
74
0100035
AR
Compound, Locking
75
4922543
1
Harness, Lift Down (Lower) (Not Shown - See ELECTRICAL
SECTION for Breakdown)
76
3300455
2
Nut #10-24
77
1001099550
2
Slider (Bottom)
77A
0440234
4
Bushing (2 Per Assembly)
78
0791406
3
Screw 1/4-20 x 3/4
79
4740438
2
Washer
80
3422927
1
Rollpin
82
0641410
2
Bolt 1/4-20 x 1-1/4
83
4740506
2
Washer
84
0275481
1
Scissors Arms Assembly (See SCISSORS ARMS ASSEMBLY
WITHOUT LSS - 3369LE/M3369 for Breakdown)
85
1001125245
1
Decal Kit - Calibration (Includes 2 Decals)
