SECTION 6 - JLG CONTROL SYSTEM
3121181
– JLG Lift –
6-63
osc axle p sw
OP/CL
Displays status of oscillating axle pressure switch. (Dis-
played if OSCILLATING AXLE = 1)
sky welder
YES/NO
Displays the status of Sky Welder selected during boom
sensor calibration. (Displayed if MODEL NUMBER = 7 or 8)
sky cutter
YES/NO
Displays the status of Sky Cutter selected during boom
sensor calibration. (Displayed if MODEL NUMBER = 7 or 8)
sky glazier
YES/NO
Displays the status of Sky Glazier selected during boom
sensor calibration. (Displayed if MODEL NUMBER = 7 or 8)
sky Bright
YES/NO
Displays the status of Sky Bright selected during boom
sensor calibration. (Displayed if MODEL NUMBER = 7 or 8)
Pipe Racks
YES/NO
Displays the status of Pipe Racks selected during boom
sensor calibration. (Displayed if MODEL NUMBER = 7 or 8)
Camera mount
YES/NO
Displays the status of Camera Mount selected during
boom sensor calibration. (Displayed if MODEL NUMBER =
7 or 8)
LOAD:
Not displayed if LOAD=NO, LENGTH=NO, and ANGLE=NO
(machine digits = 0)
LENGTH
OP /CL
Displays measured length, NOTE: Not displayed if MODEL
NUMBER = 7 or 8
ANGLE
OP / CL
Displays measured angle, NOTE: Not displayed if MODEL
NUMBER = 7 or 8
WEIGHT
XXXX%
Percentage of maximum calibrated weight on the plat-
form. An uncalibrated load cell will read 1000% Displayed
if LOAD is not 0 and LOAD TYPE is 0.
OK/OVERLOADED
Displays LSS Module load system status. Displayed if LOAD
is not 0 and LOAD TYPE is 1.
Table 6-8. Machine Diagnostics Parameters
Diagnostics
Submenu
(Displayed on
Analyzer 1
st
Line)
Parameter
(Displayed on
Analyzer 2
nd
Line)
Parameter Value
(Displayed on Analyzer 2
nd
Line)
Description
