SECTION 6 - JLG CONTROL SYSTEM
3121181
– JLG Lift –
6-25
19
LOAD TYPE
Selects if we are
using the LSS
Module, built in
load cell or the
BPE module (if
selected model
uses the Gorilla
Platform Mod-
ule)
NOTE: Not dis-
played if LOAD: is
0=NO
0=1 ON ROTATOR
Use the on-board load sensor for all models
except those models which use the Gorilla Plat-
form Module, which use the BPE module inter-
face for Platform load sensing
0
1=4 UNDER BASKET
Use the LSS Module
20
ANGLE:
Displays pres-
ence/function of
angle sensor
NOTE: 2=ANA-
LOG Not Dis-
played
1=DIGITAL
1 Limit switches are installed or switches are
not present on this model
1
2=ANALOG
2 An analog sensor is installed
21
LENGTH:
Displays pres-
ence/function of
length sensor
NOTE: 2=ANA-
LOG Not Dis-
played
1=DIGITAL
Limit switch installed or switches are not present
on this model
1
2=ANALOG
2 An analog sensor is installed
22
FUNCTION
CUTOUT:
Displays pres-
ence/function of
drive cutout.
0=NO
No Drive Cutout
0
1=BOOM CUTOUT
Boom Function Cutout While Driving Above Ele-
vation. (CE)
2=DRIVE CUTOUT
Drive Cutout Above Elevation
3=DRIVE CUT E & T
Drive Cutout Above Elevation And Tilted
23
GROUND
ALARM:
Displays/adjusts
ground alarm
presence/func-
tion
0=NO
No Ground Alarm installed
0
1=DRIVE
Travel alarm – sounds when the drive function is
active. (Option)
2=LIFT DOWN
Descent alarm – sounds when either lift down is
active. (Option)
3=BOOM & DRIVE
Motion alarm – sounds when any function is
active. (Option)
24
T PROX
SWITCHES:
Displays pres-
ence/function of
Tower Proximity
switches.
0=NO
No Tower Prox Switches Installed
0
1=YES
Tower Prox Switches Installed
Table 6-1. Machine Set-Up Parameters
Configurati
on
Digit
Parameter
Displayed on
Analyzer
Line 1
Description
Parameter
Value
Definition
Defaul
t
Numb
er
