SECTION 6 - JLG CONTROL SYSTEM
6-48 – JLG Lift – 3121181
DRIVE:
21* 0
1
2
4WD: Four wheel drive.
2WD: Two wheel drive.
2WD W/ 2-SPEED: Two wheel drive with 2-speed valve.
0
* Only visible under certain model selections.
DISPLAY UNITS:
22* 0
1
IMPERIAL: DEG F, PSI, LBS
METRIC: DEG C, KPA, KGS
0
* Certain market selections will alter default setting.
LEVELING MODE:
23* 0
1
ALL FUNCTIONS: Platform level with all functions.
LEVEL LIFT/TELESCOPE: Platform level on lift and telescope only.
0
* Only visible on 800S models.
DRIVE CONTROL:
24 0
1
2
NORMAL: Drive coils are energized from the Ground Module.
PROPULSION: Drive coils are energized from the Propulsion Module.
ENHANCED: Drive coils are energized from the Ground Module and the ground
side of the drive coils are brought back to current feedback
returns.
2
DRIVE PUMP:
25* 0
1
SAUER DANFOSS: Machine equipped with Sauer Danfoss drive pump.
EATON: Machine equipped with Eaton drive pump.
0
* Only visible on 800S models.
BOOM CONTROL:
26 0
1
NORMAL: Boom function coils are energized from the Ground Module.
ENHANCED: Boom function are energized from the Ground Module and the
ground side of the drive coils are brought back to current feedback returns.
0
FUNCTION SPEED
KNOB:
27 0
1
YES: Machine is equipped with Function Speed Knob.
NO: Machine is equipped with Operation Speed Switch.
0
Table 6-6. Machine Configuration Programming Information Software Version P6.1 to Present
Configuration Label/
Digit
Number Description
Default
Number
