SECTION 1 - SPECIFICATIONS
3121181 – JLG Lift – 1-1
SECTION 1. SPECIFICATIONS
1.1 CAPACITIES
1.2 TIRES
1.3 ENGINE
NOTE: RPM Tolerances are ± 100.
1.4 SPECIFICATIONS AND PERFORMANCE DATA
Dimensional Data
Table 1-1. Capacities
Fuel Tank 17 gallons (64.3 liters)
Hydraulic Tank 27 gallons (102 liters)
23.6 gal. (89 liters) to the Full line
on the sight gauge
Table 1-2. Tires
Size Type Pressure Weight
12x16.5 Pneumatic 90 psi (6 Bar) 128 lbs. (58 kg)
12x16.5 Foam-Filled N/A 328 lbs. (149 kg)
33/1550x16.5 Pneumatic 90 psi (6 Bar) 135 lbs. (61 kg)
33/1550x16.5 Foam-Filled N/A 395 lbs. (179 kg)
14 x 16.1 Pneumatic 40 lbs. (3 bar) 91.5 lbs. (41.5 kg)
14 x 16.1 Foam-Filled N/A 426 lbs. (193 kg)
Table 1-3. Caterpillar 3024/C2.2
Fuel Diesel
No. of Cylinders 4
BHP 46.5 hp (34 kW)
Bore 3.307 in. (84 mm)
Stroke 3.9370 in. (112 mm)
Displacement 134.3 cu. in. (2.2L)
Oil Capacity 10 qt. (9.4 L)
Compression Ratio 19:1
Firing Order 1-3-4-2
Max. RPM 2800
Table 1-4. Deutz F3M2011F/D2011L03
Fuel Diesel
No. of Cylinders 3
Bore 3.7 in. (94 mm)
Stroke 4.4 in. (112 mm)
Displacement 142 cu. in. (2331 cm³)
Oil Capacity
crankcase
cooler
total capacity
6.3 quarts (6 L)
4.75 quarts (4.5 L)
11 quarts (10.5 L)
Low RPM 1200
Mid RPM
Tower Lift, Upper Lift, Tele
Swing, Basket Level, Basket
Rotate, Jib Lift
1800
1500
High RPM 2800
Table 1-5. Perkins 404C-22
Fuel Diesel
No. of Cylinders 4
BHP 50 HP (37.3 kW)
Bore 3.3 in. (84 mm)
Stroke 3.9 in. (100 mm)
Firing Order 1-3-4-2
Displacement 135 cu.in. (2.2 L)
Oil Capacity w/filter 10 qt. (9.4 L)
Compression Ratio 23.3:1
Table 1-6. Dimensional Data
Overall Width 7.4 ft. (2.26 m)
Tailswing 0
Stowed Height 7.4 ft. (2.26 m)
Stowed Length 25.1 ft. (7.68 m)
Wheel base 7.67 ft. (2.34 m)
Turning Radius
6.5 ft. (2.0 m)
16.4 ft. (5.0 m)
6.5 ft. (2.0 m)
16.4 ft. (5.0 m)
Track Width
(12 x 16.5 tire)
(33/1550 tire)
(14 x 16.1 tire)
65.3 in. (1.66 m)
66.3 in. (1.69 m)
66.6 in. (1.69 m)
Ground Clearance 1.18 ft. (0.36 m)
