4.1.3 PUSH BUTTONS
The buttons have a dual function: they can be used to select machine functions or as numeri‑
cal keys in the service submenus.
They in fact feature an icon that represents their meaning and a number for use as a numeri‑
cal keypad.
An emergency STOP button is also available which, when pressed, stops the motor and
brings the machine to a standstill.
The pressed position of the emergency STOP button is represented on the display in position 7.
To make the machine operational again, the button must be turned and released.
For the description of the individual functions, see paragraph 6 Using the machine.
BUTTON 1:
Used to automatically raise the stabilisers.
6
FORWARDS JIB OPENING
BACKWARDS JIB FOLDING
7
FORWARDS ANTICLOCKWISE ROTATION
BACKWARDS CLOCKWISE ROTATION
8
FORWARDS RIGHT TRACK FORWARDS
BACKWARDS RIGHT TRACK BACKWARDS
9
R CLOSE BASKET LEVELLING
L OPEN BASKET LEVELLING
X17JPR0020413
