151
BOOM LIFT MODELS X17JPLUS
JLG
X17JPR0020413
9 SERVICE MENU ON THE REMOTE CONTROL
A SERVICE button is available on the remote control (ref. button 6) and is used to display the
status of the machine parameters and as assisting device for the safety checks to be carried
out on the machine, as specified in this manual.
Pressing button 6 accesses a numerical menu, controlled by the number buttons on the remo‑
te control. The meaning of these menus is explained in this manual. If after reading the
manual you still have some doubts, contact the JLG after‑sales service.
1 INPUT
2 LANGUAGE
3 ERRORS
4 RAMPS
5 CURRENT
6 OP. HOURS
7 SETTINGS
8 JOYSTICK
9 EXIT
M
ENUS 4 AND 5 ARE NOT ACCESSIBLE
9.1 INPUT MENU
This displays the signals received by the board from the various sensors fitted on the machi‑
ne and from the controls on the remote control. Each screen shows the status of the input
and options to scroll the menu:
1 PREC access the previous input
2 SUCC access the next input
9 ESCI exit the INPUT menu
ST TERR 1A
If both are ON, stabiliser 1 is resting on the ground. ST TERR 1B
ST TERR 2A
If both are ON, stabiliser 2 is resting on the ground ST TERR 2B
ST TERR 3A
If both are ON, stabiliser 3 is resting on the ground ST TERR 3B
ST TERR 4A
If both are ON, stabiliser 4 is resting on the ground ST TERR 4B
ST APERT1A
ND ST APERT1B
ST APERT2A
ND ST APERT2B
ST APERT3A
ND ST APERT3B
ST APERT4A
ND ST APERT4B
