Connecting a MIDI device
You can connect a MIDI (musical instrument digital interface) device to the
game controller port that comes on some models of the PC Compatibility
Card. To connect a MIDI device, you need a Sound Blaster–compatible
MIDI-to-joystick adapter (available from your computer dealer). For
instructions on connecting devices to the joystick port, see the next section,
“Connecting a PC Game Controller.”
Connecting a PC game controller
Some models of the PC Compatibility Card come with a game controller port.
To connect a PC game controller, such as a joystick, remove the plastic cover
on the game controller port, then plug your game controller into the port.
Game controller
Plug the game controller
into the joystick port.
Game controller
Plug the game controller
into the joystick port.
Game controller
Plug the game controller
into the joystick port.
Power Macintosh 7200
Power Macintosh 7500
Power Macintosh 7600
Power Macintosh 8500
Power Macintosh 9500
The joystick port is marked with the icon. Remove
the port cover before plugging a game controller into
the joystick port. Leave the port cover on if you are
not going to attach a game controller.
64 Chapter 3
