Apple PC Compatibility Card 12-inch card User Manual
Page 33
If there is a processor card in your computer, route the cable between the
processor card and the back panel (not over the top of the processor card).
If your computer has
a processor card
installed, route
the cable so that
it passes between
the processor card
and the computer’s
back panel as shown.
Processor card
19
Installing the Card in a Power Macintosh 7200, 7500, or 7600
