Apple PC Compatibility Card 12-inch card User Manual
Page 39
25
If you unplugged the auxiliary fan cable, reconnect it.
Not all computer models have an auxiliary fan.
Reconnect the auxiliary fan cable to the main logic board.
Auxiliary fan
The connector on
the fan cable plugs
in only one way.
(Be sure to align
the connector
as shown.)
Connector
(side view)
25
Installing the Card in a Power Macintosh 7200, 7500, or 7600
