Brocade Adapters Administrator’s Guide 85
53-1001583-01
Hardware Tests Diagnostics dialog box
A
Hardware Tests Diagnostics dialog box
The Port Tests diagnostics dialog box enables you to run tests on the port and to configure
parameters such as link speed and frame count.
Opening the dialog box
1. Select an HBA or HBA port from the device tree.
2. Select Configure > Diagnostics from the Host Connectivity Manager.
3. Click the Hardware Tests tab.
Fields and components
Using the dialog box
Refer to the following topics for specific procedures using this dialog box:
• “Configuring beaconing using HCM”
• “supportSave collection sources”
Field Description
Memory Test check box Check to run a Memory test on the port.
Ports list Select a port from the list.
PCI Loopback Test check box Check to run a PCI Loopback test on the port.
Data Pattern Type a data pattern. The default value is A5A5A5A5.
Test Cycle text box Specify the number of times the test runs. The default value is 100.
Loopback Test check box Check to run a Loopback test on the port.
Queue Test check box Check to run a Queue test on the port.
Subtest ID list Select a subtest from the list. The default is Internal.
Link Speed list Select a link speed from the list.
Frame Count Type a frame count. The default value is 8192.
Stop on Error check box Check to flag the system to stop running the test if an error occurs.
Test Log table Displays the time the test was run, the status of the test, and the
result of the test.
Start button Click to run the selected test.
Stop button Click to stop all pending tests.
