Brocade Adapters Administrator’s Guide 105
53-1001583-01
Remote Port Properties panel
A
Remote Port Properties panel
The Remote Port Properties panel enables you to display the properties that are associated with
the remote port.
Opening the properties panel
1. From the device tree, select a remote port (target or initiator).
2. Click the Remote Port Properties tab in the right pane.
NOTE
If it is a target port, there are two tabs in the right pane: Properties and LUNs.
Fields and components
Field Description
Port WWN The world wide name of the device’s port.
Node WWN The world wide name of the device.
Symbolic Name The symbolic name associated with the remote port.
Name The name associated with the device.
FC Address The remote port’s Fibre Channel address.
Device Type The type of device associated with the remote port; for example,
Disk.
Target Rate Limiting Enforced Indicates whether target rate limiting is used on the remote device.
QoS Priority The QoS priority level, which ranges between 0 (best effort) to 7 (the
highest priority).
Bus # The unique identifying number for each PCI bus, assigned during
system initialization.
Target ID The identifier of the target device.
