76 Brocade Adapters Administrator’s Guide
53-1001583-01
Duplicated Names dialog box
A
Duplicated Names dialog box
The Duplicated Names dialog box enables you to display configured names that are redundant.
Opening the dialog box
The Duplicated Names dialog box displays when you import a file with a duplicate name.
1. Select Configure > Names from the Host Connectivity Manager.
OR
Right-click a device from the device tree and select Configure Names.
The Configure Names dialog box displays.
2. Import a file with duplicate names in the Configure Names dialog box.
The Duplicated Names dialog box displays.
Fields and components
Using the dialog box
Refer to the following topics for specific procedures using this dialog box:
• “Name configuration”
• “Adding name entries”
• “Removing a name entry”
• “Exporting the properties for a WWN”
• “Importing the properties for a WWN”
Field Description
Append unique suffix for all repetitive
names button Click to automatically add an incremental number to a duplicate
name.
User/Administrator will manually fix
button Click if you want to manually fix a duplicate name.
Name The port number with which the duplicated name is associated.
WWN/MAC The world wide name or media access control address with which
the duplicated name is associated.
Operational Status The operational status of the duplicate WWN (for example,
Discovered).
Type The type of device; for example, Node or Port.
Description A description of the duplicate name.
