88 Brocade Adapters Administrator’s Guide
53-1001583-01
IOC Statistics dialog box
A
IOC Statistics dialog box
The IOC Statistics dialog box enables you to view statistics related to the input/output controller
(IOC).
Opening the dialog box
1. Select a physical port of the HBA from the device tree.
2. Select Monitor > Statistics > IOC Statistics from the Host Connectivity Manager.
Fields and components
Field Description
Keep Running Data check box Click to continue running statistical data. This is useful if you
want to see a trend.
Polling Frequency in Seconds text box Type a number for polling frequency. The range is between five
and 3600 seconds and the default is five seconds.
Start Polling button Click to manually poll the IOC statistics.
Reset button Click to reset all of the statistics to 0.
IOC Driver: Mailbox Interrupt The number of mailbox interrupts on the IOC driver.
IOC Driver: Start Events The number of start events on the IOC driver.
IOC Driver: Stop Events The number of stop events on the IOC driver.
IOC Driver: Enable Events The number of enable events on the IOC driver.
IOC Driver: Disable Events The number of disable events on the IOC driver.
IOC Driver: Heartbeat Failures The number of heartbeat failures on the IOC driver.
IOC Driver: Firmware Boots The number of firmware boots on the IOC driver.
IOC Driver: Statistics Timeouts The number of statistics timeouts on the IOC driver.
Firmware IO: host IO aborts The number of host IO aborts in the firmware.
Firmware IO: host IO Cleanup The number of host IO cleanup attempts in the firmware.
Firmware IO: IO timeouts in f/w The number of IO timeouts in the firmware.
Firmware IO: Frames parsed by f/w The number of frames parsed by the firmware.
Firmware IO: data frames The number of data frames in the firmware.
Firmware IO: fcp rsp frames The number of FCP responses on the firmware IO.
Firmware IO: xfer_rdy_frames The number of transfer ready frames.
Firmware IO: BLS ACC frames The number of BLS ACC frames on the firmware IO.
Firmware IO: target abort frames The number of aborted target frames on the firmware IO.
Firmware IO: unknown frames The number of unknown frames on the firmware IO.
Firmware IO: itn CISC updated on rsp The number of CISCs updated on response.
Firmware IO: itn CISC updated on data The number of CISCs updated on data.
Firmware IO: itn CISC updated on xfer ready The number of updates that occurred on xfer_rdy.
