Brocade Adapters Administrator’s Guide 109
53-1001583-01
Syslog Server Configuration dialog box
A
Syslog Server Configuration dialog box
The Syslog Server Configuration dialog box enables you to configure the host connectivity manager
(HCM) to send Syslog messages to other computers through port 514. You can configure the HCM
agent to forward events to a maximum of three Syslog destinations.
Opening the dialog box
1. Select the host from the device tree.
2. Select Configure > Syslog from the main menu.
Fields and components
Using the dialog box
Refer to the following topics for specific procedures using this dialog box:
• “Syslog support”
• “Registering a host server”
• “Removing a host server”
Field Description
Host name / IP Address text box Enter the host name or IP address of the destination device.
Set this IP in all discovered agents in
future check box Click to set the device as a Syslog destination in all future discovered
agents.
Add button Click to register the host as a Syslog destination.
Remove button Click to remove the host as a Syslog destination.
