bizhub 423/363/283/223 3-9
3.2 Touch panel 3
Reference
- When user authentication settings are applied, the names of documents that have not been saved by
logged in users cannot be viewed.
- The names of confidential documents are not displayed.
- The function for saving a document in the Public/Personal/Group User Box, Internet fax function, and
IP address fax function are available only when a Hard Disk is installed.
Item Description
List items No.: Job identification number assigned when the job is queued.
Address Type: Displays the destination type (including fax, E-Mail, FTP, PC
(SMB), WebDAV, TWAIN, or setting disabled
* ). "TWAIN" appears for the
job that is sent via Web service.
Status: Displays the status of the job (sending/queued/dialing/pending for
redial/deleting).
Address: Displays the fax number, E-mail address, User Box name, etc. of
the recipient's machine.
Time Stored: Displays the time that the job was queued.
Org.: Displays the number of pages in the original.
*
This is displayed when sending data while the address is deleted.
[ ][ ] When there are more than the upper limit of seven jobs to be displayed at
one time, press these buttons to display other jobs.
[Timer TX Job] Displays the status of the reserved transmission in the memory. To delete
a job, press [Delete].
[L1][L2] These buttons appear when two Fax Kit are installed. Press one of these
buttons. The job list of the selected line appears.
[Delete] Press this button to delete the selected job.
[Redial] Select a job of which the status is set to "Waiting To Redial", to perform
redialing.
[Check Job Set.] Press this button to check the settings of the selected job. Press either
[
Back] or [Forward ] to check the settings.
[Detail] Press this button to check the registration source/user name, file name,
destination type, destination, stored time, transmission, number of original
pages and external server information for the selected job. To delete a job,
press [Delete].
•
The external server information that is available by pressing [Detail] ap-
pears only when using external server authentication.
• [Type] is displayed only when the destination is a fax, Internet fax, or IP
address fax.
Item Description
List items No.: Job identification number assigned when the job is queued.
Address Type: Displays the destination type (including fax, E-Mail, FTP, PC
(SMB), WebDAV, TWAIN, or setting disabled
*
). "TWAIN" appears for the
job that is sent via Web service.
Address: Displays the fax number, E-mail address, User Box name, etc. of
the recipient's machine.
Time Stored: Displays the time that the job was queued.
Org.: Displays the number of pages in the original.
Result: Displays the result of the operation (completed successfully/delet-
ed due to error/deleted by user). "Error detected" is also displayed for
broadcasting.
*
This is displayed when sending data while the address is deleted.
[ ][ ] When there are more than the upper limit of seven jobs to be displayed at
one time, press these buttons to display other jobs.
[Deleted Jobs]/[Finished
Jobs]/[All Jobs] Switch to display the job type.
