10. CONTROL PORT REGISTER SUMMARY
10.1 Memory Address Pointer (MAP)
INCR - Auto Increment Address Control Bit
Default = ‘0’
0 - Disable
1 - Enable
MAP6:MAP0 - Register address
Note: Reserved registers must not be written to during normal operation. Some reserved registers are used for test
modes, which can completely alter the normal operation of the CS8427.
Addr
(HEX)
Function 7 6 5 4 3 2 1 0
00 Reserved 0 0 0 0 0 0 0 0
01 Control 1 SWCLK VSET MUTESAO MUTEAES 0 INT1 INT0 TCBLD
02 Control 2 0 HOLD1 HOLD0 RMCKF MMR MMT MMTCS MMTLR
03 Data Flow Control 0 TXOFF AESBP TXD1 TXD0 SPD1 SPD0 0
04 Clock Source Control 0 RUN CLK1 CLK0 OUTC INC RXD1 RXD0
05 Serial Input Format SIMS SISF SIRES1 SIRES0 SIJUST SIDEL SISPOL SILRPOL
06 Serial Output Format SOMS SOSF SORES1 SORES0 SOJUST SODEL SOSPOL SOLRPOL
07 Interrupt 1 Status TSLIP OSLIP 0 0 0 DETC EFTC RERR
08 Interrupt 2 Status 0 0 0 0 EFTU QCH 0
09 Interrupt 1 Mask TSLIPM OSLIPM 0 0 0 DETCM EFTCM RERRM
0A Interrupt 1 Mode (MSB) TSLIP1 OSLIP1 0 0 0 DETC1 EFTC1 RERR1
0B Interrupt 1 Mode (LSB) TSLIP0 OSLIP0 0 0 0 DETC0 EFTC0 RERR0
0C Interrupt 2 Mask 0 0 0 0 DETUM EFTUM QCHM 0
0D Interrupt 2 Mode (MSB) 0 0 0 0 DETU1 EFTU1 QCH1 0
0E Interrupt 2 Mode (LSB) 0 0 0 0 DETU0 EFTU0 QCH0 0
0F Receiver CS Data AUX3 AUX2 AUX1 AUX0 PRO AUDIO COPY ORIG
10 Receiver Errors 0 QCRC CCRC UNLOCK V CONF BIP PAR
11 Receiver Error Mask 0 QCRCM CCRCM UNLOCKM VM CONFM BIPM PARM
12 CS Data Buffer Control 0 0 BSEL CBMR DETCI EFTCI CAM CHS
13 U Data Buffer Control 0 0 0 UD UBM1 UBM0 DETUI EFTUI
14-1D Q sub-code Data
1E OMCK/RMCK Ratio ORR7 ORR6 ORR5 ORR4 ORR3 ORR2 ORR1 ORR0
1F Reserved
20-37 C or U Data Buffer
7F ID and Version ID3 ID2 ID1 ID0 VER3 VER2 VER1 VER0
Table 1. Control Register Map Summary
7 6 5 4 3 2 1 0
INCR MAP6 MAP5 MAP4 MAP3 MAP2 MAP1 MAP0
