VLAN Commands
4-171
4
Example
The following example shows how to set the interface configuration mode to
VLAN 1, and then assign an IP address to the VLAN:
Related Commands
switchport mode
This command configures the VLAN membership mode for a port. Use the no form
to restore the default.
Syntax
switchport mode {trunk | hybrid}
no switchport mode
• trunk - Specifies a port as an end-point for a VLAN trunk. A trunk is a direct
link between two switches, so the port transmits tagged frames that identify
the source VLAN. Note that frames belonging to the port’s default VLAN
(i.e., associated with the PVID) are also transmitted as tagged frames.
• hybrid - Specifies a hybrid VLAN interface. The port may transmit tagged
or untagged frames.
Default Setting
All ports are in hybrid mode with the PVID set to VLAN 1.
Command Mode
Interface Configuration (Ethernet Ports 1-8, Port Channel)
Example
The following shows how to set the configuration mode to port 1, and then set the
switchport mode to hybrid:
Related Commands
switchport acceptable-frame-types (4-172)
Console(config)#interface vlan 1
Console(config-if)#ip address 192.168.1.254 255.255.255.0
Console(config-if)#
Console(config)#interface ethernet 1/1
Console(config-if)#switchport mode hybrid
Console(config-if)#
