Spanning Tree Algorithm Configuration
3-123
3
CLI – This example shows the STA attributes for port 5.
Configuring Interface Settings
You can configure RSTP and MSTP attributes for specific interfaces, including port
priority, path cost, link type, and edge port. You may use a different priority or path
cost for ports of the same media type to indicate the preferred path, link type to
indicate a point-to-point connection or shared-media connection, and edge port to
indicate if the attached device can support fast forwarding. (References to “ports” in
this section means “interfaces,” which includes both ports and trunks.)
Command Attributes
The following attributes are read-only and cannot be changed:
• Port – Port identifier. (Range: 1-8)
• STA State – Displays current state of this port within the Spanning Tree.
(See Displaying Interface Settings on page 3-120 for additional information.)
• Discarding - Port receives STA configuration messages, but does not forward
packets.
• Learning - Port has transmitted configuration messages for an interval set by
the Forward Delay parameter without receiving contradictory information. Port
address table is cleared, and the port begins learning addresses.
• Forwarding - Port forwards packets, and continues learning addresses.
• Trunk
16
– Indicates if a port is a member of a trunk.
Console#show spanning-tree ethernet 1/5
Eth
1/ 5 information
--------------------------------------------------------------
Admin status:
enabled
Role:
disable
State:
discarding
External admin path cost: 1000
Internal admin cost:
1000
External oper path cost:
1000
Internal oper path cost:
1000
Priority:
128
Designated cost:
0
Designated port:
128.5
Designated root:
32768.0.0000E8AAAA00
Designated bridge:
32768.0.0030F1D473A0
Fast forwarding:
disabled
Forward transitions:
2
Admin edge port:
disabled
Oper edge port:
disabled
Admin Link type:
auto
Oper Link type:
point-to-point
Spanning Tree Status:
enabled
Console#
16. STA Port Configuration only
