Configuring the Switch
3-120
3
CLI – This example enables Spanning Tree Protocol, sets the mode to MST, and
then configures the STA and MSTP parameters.
Displaying Interface Settings
The STA Port Information and STA Trunk Information pages display the current
status of ports and trunks in the Spanning Tree.
Field Attributes
• Port – Ports 1 - 8.
• Spanning Tree – Shows if STA has been enabled on this interface.
• STA Status – Displays current state of this port within the Spanning Tree:
- Discarding - Port receives STA configuration messages, but does not forward
packets.
- Learning - Port has transmitted configuration messages for an interval set by
the Forward Delay parameter without receiving contradictory information. Port
address table is cleared, and the port begins learning addresses.
- Forwarding - Port forwards packets, and continues learning addresses.
The rules defining port status are:
- A port on a network segment with no other STA compliant bridging device is
always forwarding.
- If two ports of a switch are connected to the same segment and there is no other
STA device attached to this segment, the port with the smaller ID forwards
packets and the other is discarding.
- All ports are discarding when the switch is booted, then some of them change
state to learning, and then to forwarding.
• Forward Transitions – The number of times this port has transitioned from the
Learning state to the Forwarding state.
• Designated Cost – The cost for a packet to travel from this port to the root in the
current Spanning Tree configuration. The slower the media, the higher the cost.
• Designated Bridge – The bridge priority and MAC address of the device through
which this port must communicate to reach the root of the Spanning Tree.
Console(config)#spanning-tree 4-151
Console(config)#spanning-tree mode mstp 4-151
Console(config)#spanning-tree priority 40000 4-154
Console(config)#spanning-tree hello-time 5 4-153
Console(config)#spanning-tree max-age 38 4-153
Console(config)#spanning-tree forward-time 20 4-152
Console(config)#spanning-tree pathcost method long 4-155
Console(config)#spanning-tree transmission-limit 4 4-155
Console(config)#Console(config)#spanning-tree mst-configuration 4-156
Console(config-mstp)#revision 1 4-158
Console(config-mstp)#name R&D 4-157
Console(config-mstp)#max-hops 30 4-159
Console(config-mstp)#
