2-48 AMERICAN-LINCOLN TECHNOLOGY
SMART 2000
Key No. Part Number Description Qty.
1 7-05-07179 Bar - Battery 1
2 2-00-03306 Bearing - Ball 16
3 7-08-00980 Brkt - Filter MTG Ref.
4 7-08-00978 Brkt - Front Mtr Mtg Ref.
5 7-08-00977 Brkt - Rear Mtr Mtg Ref.
6 2-95-04182 Nut - 3/8-16 Elastic Stop Nut 4
7 7-51-05017 Pan - Battery 1
8 7-57-05063 Pivot - Battery Bar 1
9 7-75-01199 Spacer - Battery Stop (510 A.H.) 1
10 7-78-05029 Stop - Battery (720 A.H.) 1
11 7-81-00224 Support - Battery Ref.
HARDWARE USED:
H35 2-00-02708 Screw, 5/16-18 x 1.000 HHM 2
H46 2-00-00644 Nut, 5/16-18, Insert Fiber 2
H48 2-00-00233 Screw, 3/8-16 x 1.000 HHC 4
H58 2-00-00241 Screw, 1/2-13 x 1.750 HHC 3
H62 2-00-00405 Flat Washer, 1.063 x .531 x .094 9
H65 2-00-04936 Nut, ½-13 Fiber Lock 5
H148 2-00-01778 Screw, 1/2-13 x 2.000 HHC 1
H213 2-00-01254 Screw, ½-13 x 1.500 HHCS 1
C1929/0012
ROLLOUT BATTERY - PARTS LIST
