2-34 AMERICAN-LINCOLN TECHNOLOGY
SMART 2000
RECOVERY TANK- PARTS LIST
Key No. Part Number Description Qty.
1 7-83-04178-1 Tank, Recovery 1
2 7-58-05299 Plate, Vac Inlet (welded) 1
3 7-26-04012 Float, Recovery 1
4 7-10-04008 Float Cage 1
5 7-33-02427 Hose, Recovery Tank Inlet 1
6 2-00-02216 Hose Clamp 5
7 7-33-02397 Hose, Squeegee 1
8 7-87-02203 Tube - Vacuum Hose 1
9 7-33-02420 Hose - Lower Squeegee 1
10 0775-164 Float Switch (gray) 1
11 7-09-01122 Bushing 1
12 7-31-07027 Hanger, Drain Hose 1
13 7-80-05086 Stud, Clean out Door 2
14 7-29-00250 Gasket, Recovery Tank Drain 1
15 7-19-08063 Door, Recovery Tank Drain 1
16 25201A Knob 2
17 7-33-02396 Hose, Drain 1
18 7-87-02201 Tube, Drain 1
19 7-33-02405 Hose, Drain 1
20 7-29-00265 Gasket, Vac Recovery 1
21 2-95-04689 Washer - Axle 3
22 2-14-03197 Washer - Neoprene, 1 x .19 x 1/8 4
HARDWARE USED:
H24 2-00-00220 Screw, 1/4-20 x .625 HHC 2
H29 2-00-04966 Screw, 1/4-20 x 1.500 HHM 2
H30 2-00-04687 Lock Washer, Helical Spring 1/4 Med. 2
H32 2-00-04688 Nut, 1/4-20 Hex. 2
H47 2-00-00232 Screw, 3/8-16 x .750 HHC 3
H53 2-00-02310 Lock Washer, Helical Spring 3/8 Med. 3
H72 2-00-00518 Lock Washer, Helical Spring 2
H94 2-00-00410 Flatwasher, .875 x .375 x .060 2
H126 2-00-03466 Screw, #10-16 x .500 8
H136 2-00-03940 Screw, #10-24 x .500 T/C HH 4
H230 2-00-00466 Flat Washer, .625 x .203 x .031 4
H346 2-00-05237 Washer - Flat .063 x .265 x .063 4
C1919/0106
